Now, assuming that you have followed all the instructions which are mentioned in the last article of Software as well as hardware tweaks to Root Google TV, you can now proceed to this article wherein we will see on how you can install the applications in your Google TV. Please note that all the applications of Android can now be accommodated in the Google TV and supports the Logitech Revue Set top boxes. The only condition to install the apps in your Google TV is that you will have to follow the instructions carefully. As of now this procedure will only support the Google TV Revue Boxes powered by the Logitech.
Logitech revue google tv free download - Google Home, Radio for Google Chrome, Google app for Android TV, and many more programs. Watch Online TV Stations with automatic list updates.
Now, as soon as you finish the above process of software as well as the hardware tweak, you will now need to proceed to rebooting the Logitech Revue while running the Android Debug Bridge (ADB) for allowing the remote connections on Port 5555. Just in case if the Android SDK is already installed in your device then you are ready to begin installing applications with the standard ‘adb install’ commands or accessing shell via “adb shell”. Just in case if you are unable to understand the ADB Steps which are mentioned then you will have to follow the procedure which is mentioned below
Procedure to install the Applications in the Google TV (Logitech Revue):
Logitech Revue Update
[HOW TO] Install Kodi on Google TV: Kodi/XBMC Works Well Now. I have no experience with version 4.2.2 but based on what I have read I would say it is better overall, although not everything about it is better. Kodi for logitech revue, kodi google tv, kodi logitech revue, kodi on google tv, kodi on logitech revue. 4 SONY NSZ-GS7/8 - 2nd Generation Google-TV with ARM Chip, That hopefully are going to receive this month the latest Jelly Bean 4.2.2 update. 4 Logitech REVUE and 1 Sony NSZ-GT1 - 1st Generation Google-TV, That Unfortunatelly not will get any Update anymore and will Stay forever with the Old Honeycomb, due to the fact that they use Intel chips.
- First up you will have to follow the steps which are mentioned in the mentioned link for installing the Android 2.1 SDK in your computer where you wish to install the apps. Also, you don’t have to worry about the USB drivers as this will be taken care by the ADB installation. Ensure that you are installing the adb in the default path.
- After this you will have to find the IP Address of your Google TV Revue by checking with the DHCP Server or from the option of the “Network information” in the Setting application. It will be referred to as the Google TV IP in the due course of this article.
- Now, after finding the IP you will now have to open the Shell which is in the path bash/cygwin/dos/etc on the computer in which the Android SDK is installed.
- So after verifying the SDK Tools directory which is in the path, you will now have to run the command as “ADB connect <Google TV IP>:5555” after which you will see on screen,
$ adb connect 10.10.10.50:5555
connected to 10.10.10.50:5555
- Now, you will have to change the directory which contains the Android Package (APK) which you wish to install and run “adb install app.apk” in which the “app” word stands for the application’s name.
$ adb install Maps.apk
pkg: /data/local/tmp/Maps.apk
Success
1062 KB/s (3993846 bytes in 3.672s)
- Please note that just in case if ADB didn’t report and of th errors then your application should be available in the Logitech Revue Applications List. Please note that some Android apps make use of native code which runs outside of the Dalvik VM. These native pieces will need to be rebuilt for the Revue’s x86 architecture.
That’s it you have now successfully installed the applications in your Google TV. Do let us know just in case if you face any issues or problems as we will ensure that all your issues are solved att he earliest.
Introduction
The Logitech Revue is the first set-top box device on the market with Google TV. We took a gander inside this little box to see how it stacks up with its recently-exposed rival, the Apple TV.
Want to stay up-to-date with the hardware world? Follow @ifixit!
This teardown is not a repair guide. To repair your Logitech Revue, use our service manual.
The Logitech Revue with Google TV finally makes its way into the hands of iFixit.
Although other options exist, the Revue ships with a custom keyboard controller, with built-in multi touch trackpad.
Things you can do with the Logitech Revue and Google TV:
Watch Television
Watch Movies
Browse the Internet
Use Apps
Combine any of the above options any way you like.
Some of the ports found on the Revue:
HDMI In / HDMI Out
2x IR Blasters
2x USB
Ethernet
SPDIF
Vents on the sides of the Revue help keep the motherboard nice and cool.
Up and Atom! Looks like today's teardown will feature an Intel chip.
We figured there were screws underneath the rubber pads, and we were correct.
Four #2 Phillips screws lurked beneath and were the first to come out.
This is much easier than the two-handed pry required to open the Apple TV.
Once the bottom screws were removed, it was as simple as inserting a plastic opening tool into the plastic seam and prying the two halves apart.
There are a bunch of clips around the perimeter of the device, so we had to be careful not to break any of them.
The cover comes off just like that, revealing a beautiful blue motherboard within.
There's a fan approximately twice the size of the new MacBook Air's fan on the top cover of the
Google TVLogitech Revue.The internal fan is attached to a nifty duct that directs the air flow across the CPU heat sink (located in the area shaded in red when the device is assembled) toward the vents on the side of the top cover.
Compare this to the fanless Apple TV that relies on conduction and natural convection to dissipate its internally generated heat.
It's a very simple layout inside -- just one large motherboard, brought to you by Gigabyte.
There's tons of unused space inside. The extra room should keep the Revue pretty cool and prevent any serious overheating from taking place.
Still, it is quite the departure from the 'as small as possible' route Apple has chosen to take with the Apple TV.
Next, a spudger is used to disconnect the Wi-Fi antenna cable.
This style of IPEX MHF connector is widely used in the electronics world as an antenna connector.
A #1 Phillips screwdriver makes short work of the single screw securing the Wi-Fi card to the lower case.
Finally, the Wi-Fi card can be lifted off the pins connecting it to the main board.
The 802.11 b/g/n Wi-Fi board is manufactured by AzureWave.
De-soldering the protective cap reveals an Atheros AR9271 featuring an on-board CPU and RAM to run WLAN functions on the chip itself, taking load off other components on the main board.
On the back of the Wi-Fi board lies an Atmel H024 IC.
A couple Phillips screws secure the IR sensor and RF transceiver boards to the lower case.
Before the IR sensor board can be removed, the RF transceiver board must be lifted off the pins connecting it to the main board.
A Nordic Semiconductor RF24LU1 transceiver is attached to the top of the board. This chip is responsible for receiving and transmitting signals with the wireless keyboard.
Removing the IR board, which contains four LEDs -- two regular and two infrared.
Combining open-world gameplay with a character driven narrative, you arrive in a town brimming with delights and degradation and given the opportunity to take it over as you choose. From the decade of big hair, excess and pastel suits comes a story of one man’s rise to the top of the criminal pile. Vice City, a huge urban sprawl ranging from the beach to the swamps and the glitz to the ghetto, was one of the most varied, complete and alive digital cities ever created. Gta vice city free download apk.
We assume that the black plastic component in the center is the receiver for the IR signals.
We take off the heatsink to reveal the Atom processor. The heatsink is held in place by two Phillips screws -- no need to reinvent the wheel here..
The Intel Atom CE4150 1.2 GHz processor.
So how does the Atom CE4150 stack up against the A4 processor?
The Intel CE4150 is clocked at 1.2 GHz, whereas the Apple A4 processor is capped at 1.0 GHz.
The architecture of the Apple A4 revolves around its package-on-package (PoP) design, encompassing both processor and RAM into one design. The Atom CE4150 design relies on external RAM chips.
Contents of the Gigabyte GA-SBKAN2:
Intel Atom CE4150 1.2 GHz processor, with a 400 MHz GPU
Samsung K9F8G08U0M 1 GB NAND Flash
Hynix H27UBG8T2ATR 4 GB NAND Flash
Silicon Image Sil9135 HDMI 1.3 Receiver
Nanya NT5CB128M8CN-CG 1 GB DDR3 SDRAM (1 Gb X 8)
Realtek Semiconductor RTL8201N 10/100M PHYceiver
Microchip PIC24FJ64GA004-I/PT 16-bit microcontroller
Being the tinkerers that we are, we had to take a look inside the keyboard.
On the reverse of the touch pad is a Synaptics T1021A touch controller, also found in the Microsoft Kin Two and the Sony Ericsson Xperia X10 Mini E10i. Native instruments maschine serial key keygen.
A Nordic Semiconductor nRF24LE1 found near the batteries most likely provides wireless connectivity to the Revue base station.
Logitech Revue Repairability: 8 out of 10 (10 is easiest to repair).
Opening the case is super-simple -- only 4 screws and a bunch of clips stand in your way.
Only standard Phillips screws are used.
Daughterboard connectors easily disconnect from the motherboard sockets.
The fan is very easy to replace, should it ever fail.
If you have to replace anything on the motherboard, you have to replace the entire board.
